Maximet GMX200 Compact Weather Station
Wind speed and direction measurements are provided via an ultrasonic sensor and the addition of an electronic compass provides apparent wind measurements. Average speed and direction together with WMO averages and gusts data is also provided. Add GPS (optional) to provide true wind and other features.
WIND
- Wind speed & direction
- Apparent and true wind (with GPS)
- WMO wind averages and gust
- Compass
- GPS (optional) gives height above sea level, latitude and longitude
GPS (Option)
- Height above sea level (m)
- MSL pressure
- Sunrise/sunset
- Position of the sun
- Twilight
- Solar Noon
Parameters
- Wind speed (m/s, km/hr, mph, kts, ft/min)
- Wind direction
- True/apparent wind
- Angle of Tilt
- Outputs (RS232, 422, 485 (ASCII), SDI-12, NMEA, MODBUS, Analogue (option))
- Quality Measurements
- Lightweight and Robust
- Low Power Mode
- Free of charge software
- Gill proven reliability
- Compact integrated design
- Real-time output
- Easy installation
- Gill in-house wind tunnel calirbration & validation
WIND SPEED |
|
| Range | 0.01m/s to 60m/s |
| Accuracy |
± 3% to 40m/s, ±5% to 60m/s |
| Resolution m/s | 0.01 |
| Sampling rate | 0.01m/s |
| Units | m/s, km/hr, mph, kts, ft/min |
WIND DIRECTION |
|
| Range | 0 - 360° |
| Accuracy |
± 3° to 40m/s, ±5° to 60m/s |
| Resolution | 1° |
| Starting Threshold | 0.05m/s |
| Sampling Rate | 1Hz |
| Units | Degrees |
OUTPUTS |
|
| Output rate | 1/s, 1/min, 1/hr |
| Digital Comms Modes | Serial RS232, RS422, RS485, SDI-12, NMEA, MODBUS, ASCII |
| Analogue Outputs | Available via separate optional device |
POWER |
|
| Power Supply | 5 to 30 Vdc |
| Power (Nominal) 12Vdc | 25mA continuous high mode. 0.7mA eco-power mode (1 hour polled) |
ENVIRONMENTAL CONDITIONS |
|
| IP Rating | 66 |
| Operational Temperature Range | -35°C to +70°C |
| EMC Standard: | BS EN61326-2-1:2013 FCC, CFR Title 47, Part 15, Subpart B, Class A digital device |
| CE Marking | YES |
| RoHS Compliant | YES |
| Weight | 0.5Kg |
| Origin | UK |
