- Rugged and accurate sampling for almost all solid and liquid substances.
- Suitable for laboratory as well as production applications.
- A micro processor controlled weight loss dehydration method of moisture analysis
- Offers accurate and efficient results.
- This process uses infrared drying
- Continuous weight loss measurement.
| WEIGHING RANGE: | Selectable 60 / 120 / 310 g |
| RESOLUTION: | 0,001 g / 0.002 / 0.005 g |
| MEASURED VALUES: |
% Decrease of weight in grams % dry material increase of weight in grams % dry substance actual sample weight gram solids per kg |
| TIMER: | Free programmable 0...90 min. in 10 second steps for time depending drying |
| KONSTA STOP: | Automatic drying until weight is constant. Selectable in 3 different modes: start measuring, measuring in intervals, weight loss/measured during intervals. |
| HIGH-FLASH: | Automatic, variable pre-heater to shorten the drying time up to 50% depending on the material or to reach the set-point temperature much earlier. |
| TEMPERATURE: | Selectable either free variable or with 100 steps range approx. 40...180°C with light heater, or up to 360°C with quartz heater |
| POWER FROM HEATER: |
250 watts (infrared light heater) 375 watts (quartz dark heater) |
| SAMPLE WEIGHT: | Minimum 1 g, recommended minimum 4 g |
| SAMPLE VOLUME: | Max. 95 cm3 |
| DRYING BOWL: | Stainless steel, diameter 110 mm |
| DATA OUTPUT: | Interface V24/RS 232 |
| DATA SIGNALS: |
All weight and measuring data in GLP-format with start time and variable interval print out. Selectable date, time, total measuring time, type of sample |
| POWER SUPPLY: | 230 V (115 V with separate transformer) +/- 15%, 48-63 Hz |
| POWER CONSUMP.: | 275 VA or 400 VA |
