MI-520 PV Module Selector
x12 channel PV module measuring
The MI-520 PV Module Selector provides x12 channels to measure PV modules sequentially and works with the MP-160 I-V Tracer to test the long-term stability and I-V characteristics of multiple PV cells and modules.
The MI-520 PV Module Selector provides x12 channels to measure PV modules sequentially and works with the multi-channel MP-160 I-V Tracer to test the long-term stability and individual I-V characteristics of multiple PV cells and modules.
Up to x4 units of the MI-520 can be connected to the MP-160.
- Switching capacity 100V / 7A
- Up to x4 module selectors
- Compatible with the MP-160 I-V Tracer
| Measurement range Voltage | 0.05 to 300 V |
| Measurement range Current | 0.005 to 7 A |
| Measurement range Power | 0 to 300 W |
| Operating temperature range | 0 to 40°C |
| Power supply | 100 to 240 VAC, 30W |
| Dimensions mm | 370 (W) x 350 (D) x 133 (H) |
| Weight | 5 kg |
| Input channels | 12 |
| Max. devices | 4 |
