MI-540 Temperature Selector
x12 input channels
The MI-540 supports backside PV module temperature monitoring, offering greater insight into PV performance, management, and potential optimisation.
PV panel efficiency is affected by temperature. Accurately measuring front and rear-side temperature can provide greater insight into PV performance, management, and potential optimisation.
The MI-540 provides x12 channels for measuring PV module temperatures using a T-type thermocouple for backside PV module temperature monitoring.
- For PV cells & modules up to 300W
- Switching capacity 100V / 7A
| Operating temperature range | 0 to 40°C |
| Power supply | 100 to 240 VAC, 30W |
| Dimensions mm | 370 (W) x 350 (D) x 133 (H) |
| Weight | 5 kg |
| Input channels | 12 |
| Max. devices | 4 |
| Thermocouple T-Type | Max. 12 sensors |
